Cable length: 30m.
The connection between the FXCPU (MINI-DIN8 pin connector) and the graphic operation terminal.
Connection between FXCPU communication function extension board (MINI-DIN8 pin connector) and GOT.
Applicable models: GT10, GT21. Can be used as a screw relay terminal.A set of 5 (LOGO removable, man-machine interface provides one).
Applicable model: A960GOT. Motor series: medium inertia, medium capacity FX2N-16MR-DS
Using a serial absolute / incremental encoder.
Rated output power: 1.5kw.
Rated speed: 3000rpm.
With a brake band.
Shaft end: straight shaft.
When the AC servo motor has no control voltage, only the pulsating magnetic field generated by the excitation winding is generated in the stator, and the rotor is still not moving.
When the control voltage is controlled, a rotating magnetic field is generated in the stator, and the rotor rotates in the direction of the rotating magnetic field,
In the case of constant load, the speed of the motor varies with the size of the control voltage,
When the phase of the control voltage is reversed, the servo motor will reverse.SSCNET III /H remote station.
Transmission speed: 150Mbps.
Play the role of SSCNET III /H remote station
SSCNET III /H host module is the MELSEC-L series of input and output modules and intelligent function modules connected to the SSCNET III /H module.
Can be used as a remote station of motion controller,
The flexible configuration of I/O module and intelligent function module is realized,
Reduce device wiring, save space.
In addition, the module can be used for the input and output of the motion controller by the circulating transmission, and the module of the SSCNET III /H host module can be installed. Motor series: ultra low inertia, low power.
Rated output power: 0.05kw.
Rated speed: 3000r/min.
Whether to bring the brakes: with.
Axis end: D type shaft.
Protection level: IP55 does not include the shaft part and the connector.
Features: ultra low inertia is suitable for high frequency operation.
Application examples: the insertion device, the assembly machine.
FX2N-16MR-DS Operation manual / Instructions / Catalog download link: /searchDownload.html?Search=FX2N-16MR-DS&select=5
